RCinPower EX2207

What it pulls

RCinPower’s own bench test, one line per prop. Drag across the chart to move the throttle; the model above follows.

What you get

• For 5-inch freestyle and racing

  RCinPower's photo bills the EX 2207 as a 5-inch freestyle and racing motor.

  Source: RCinPower photo

• 29.9 g

  29.9 g with 2 cm of lead for the 1980KV; the 2500KV is 33 g.

  Source: RCinPower 1980KV sheet, RCinPower 2500KV sheet

• Hollow shaft

  A 4 mm hollow shaft with a 5 mm thread standing 13.1 mm above the bell.

  Source: RCinPower 1980KV sheet

• Bench data on five 5-inch props

  Gemfan, HQProp and DALProp props at two voltages per KV, with the temperature after 5 s at full throttle (up to 85 °C).

  Source: RCinPower 1980KV sheet, RCinPower 2500KV sheet

What to pair it with

Our reading of RCinPower’s numbers, so your build matches what the motor was tested with.

ESC

RCinPower rates the 1980KV at 46.3 A and the 2500KV at 57.8 A. On its bench the 1980KV drew up to 47.2 A on 6S and the 2500KV up to 57.8 A on 4S. A 50 A ESC covers the 1980KV; the 2500KV on 4S needs 60 A. (RCinPower 1980KV sheet, RCinPower 2500KV sheet)

Props

Tested on the Gemfan 5136 and 51466, HQProp R36 and R38, and DALProp T5148.5. The Gemfan 51466 pulled the most on both KVs: 1,948 g on 6S (1980KV) and 1,758 g on 4S (2500KV). (RCinPower 1980KV sheet, RCinPower 2500KV sheet)

Battery

5S–6S for the 1980KV, 3S–4S for the 2500KV. (RCinPower 1980KV sheet, RCinPower 2500KV sheet)

Frame

Four M3 screws, opposite holes 16 mm apart (16 × 16). (RCinPower 1980KV sheet)

Where to buy

• AliExpress1980KV or 2500KV; the listing that shows RCinPower's spec sheets
  price on the store’s page
  Visit

Plain links, not affiliate links. Prices change; the store’s page has the current one.

Full specs

Bench data

Redrawn from RCinPower’s test reports. Thrust is static pull on a bench, more than you get in flight. Power is volts × amps; efficiency is thrust divided by power.

Inside the motor

A brushless outrunner: the coils stand still in the middle and the magnets spin around them. From the top down:

• Shaft. 4 mm hollow; 5 mm across the thread, which stands 13.1 mm above the bell. (RCinPower 1980KV sheet)
• Stator. The coils are wound on a stack of thin steel laminations: 22 × 7 mm (2207). (RCinPower 1980KV sheet)
• Base. 4 × M3 holes, opposite holes 16 mm apart (16 × 16). (RCinPower 1980KV sheet)

How fast it spins

KV is the motor’s no-load speed per volt. With nothing on the shaft, the 1980KV version reaches about these speeds; a prop loads the motor and brings it down, typically to around 70–75% of these figures at full throttle.

A 14-pole rotor has 7 pole pairs, so every turn of the shaft is 7 electrical cycles, and a six-step ESC switches the phases 42 times per turn.

About the 3D model

A generic outrunner drawn from RCinPower’s published sizes: the 22 × 7 mm stator, 27 mm bell, 18.65 mm height, 5 mm shaft, 16 mm mounting circle and 12 teeth and 14 magnets. Anything RCinPower doesn’t publish is typical for a motor this size, and the bell’s spoked top, the base and the inside are a generic design, not this motor’s. The colours are read off the maker’s product photos. There are no logos or markings: it is our drawing, not the maker’s.

Sources

1. RCinPower: EX V2 - 2207 1980KV spec sheet (RCinPower's own sheet: spec table, render, drawing, bench tables at 21 V and 24 V with temperatures after 5 s at full throttle). RCinPower's site has no page for the EX2207; the sheet is shown on an AliExpress listing and served from AliExpress's image CDN. Retrieved Oct 19, 2026.
2. RCinPower: EX V2 - 2207 2500KV spec sheet (RCinPower's own sheet from the same listing; bench tables at 12 V and 16 V). Retrieved Oct 19, 2026.
3. RCinPower: EX 2207 product photo with RCinPower's logo, billing it for 5-inch freestyle and racing on 4–6S in 2500KV and 1980KV (from the same listing), used for finish. Retrieved Oct 19, 2026.
