8- to 10-inch long-range FPV motor
Axisflying AE3115
Axisflying's AE-series 3115 for 8–10-inch long range and heavy lift: 113.5 g without cable, and 4185 g at full throttle on a GF 10*5 three-blade at 25 V.
- 8–10-inch long range and heavy lift
- 3S–6S
- 9- and 10-inch three-blade props
The spin is an illustration: the model turns at 1/600 of the no-load speed, and it is a generic 3115 motor drawn from Axisflying’s published sizes, not its exact design. Thrust, current and power are Axisflying’s bench figures for the GF 10*5 3-blade prop at 25 V, read straight across between its throttle steps. Its data starts at 50% throttle.
- Max thrust
- 4,185 g
- GF 10*5 3-blade prop, 25 V
- Weight
- 113.5 g
- without cable
- Peak current
- 64.7 A
- full throttle
- Max power
- 1,617 W
- full throttle
from $35.90a motor at Axisflying
A set of four: $143.60
Price seen Oct 19, 2026. Plain links: we earn nothing from them.
What it pulls
Axisflying’s own bench test, one line per prop. Drag across the chart to move the throttle; the model above follows.
At 60% with the GF 10*5 3-blade: 1,933 g of thrust, 18.2 A, 455 W, 4.25 g per watt.
On your quad
25.8 : 1
Thrust to weight at full throttle: four motors pull 16,740 g with the GF 10*5 3-blade at 25 V.
At 60% throttle they pull 7,732 g, 11.9 times the quad’s weight.
All-up weight is the quad ready to fly, with its battery and camera. The thrust is the maker’s static bench figure; in the air it is lower.
What you get for $35.90
AE series
The AE3115 is part of Axisflying's AE motor series; Axisflying says it controls cost without giving up materials, power or durability, and sells it for 8-, 9- and 10-inch long-range, heavy-lift and cinematic drones.
Source: Axisflying product page
Bench numbers
At 25 V and full throttle: 3712 g at 58.1 A on an HQ MQ 9*5 three-blade and 4185 g at 64.7 A on a GF 10*5 three-blade.
Source: Axisflying test data
What to pair it with
Our reading of Axisflying’s numbers, so your build matches what the motor was tested with.
- ESC
- 64.7 A at full throttle on a GF 10*5 three-blade at 25 V; 58.1 A on an HQ MQ 9*5. (Axisflying test data)
- Props
- The GF 10*5 pulls more than the HQ MQ 9*5 and runs hotter: 98.3 °C against 75.6 °C. (Axisflying test data)
- Battery
- 3S–6S; the bench data is at 25 V (6S). (Axisflying specs and drawing, Axisflying test data)
- Frame
- Four M3 screws on a 19 mm circle. (Axisflying specs and drawing)
Where to buy
- Axisflyingthe maker's store; also sold as a set of four for $133.60$35.90seen Oct 19, 2026Visit
Plain links, not affiliate links. Prices change; the store’s page has the current one.
Full specs
| Spec | Value | Source |
|---|---|---|
| KV | 900 rpm/V | Axisflying specs and drawing |
| Stator | 31 × 15 mm (3115) (from the size in Axisflying's name) | Axisflying product page |
| Configuration | 12N14P (12 stator slots, 14 magnet poles) | Axisflying specs and drawing |
| Battery | 3S–6S LiPo | Axisflying specs and drawing |
| Weight | 113.5 g (without cable) | Axisflying specs and drawing |
| Dimensions | φ37.1 × 31.5 mm without the shaft, which stands 16.7 mm above the bell | Axisflying specs and drawing |
| Shaft | 5 mm, M5 thread (11.2 mm of thread), protrudes 16.7 mm | Axisflying specs and drawing |
| Mounting | 4 × M3 on a 19 mm circle | Axisflying specs and drawing |
| Internal resistance | 0.046 Ω | Axisflying specs and drawing |
| No-load current | 1.28 A (at 12 V) | Axisflying specs and drawing |
| Max current | 64.7 A (the full-throttle row on a GF 10*5 three-blade at 25 V (S3)) | Axisflying specs and drawing |
| Max power | 1,617 W (the full-throttle row on a GF 10*5 three-blade (S3)) | Axisflying specs and drawing |
| Leads | 18 AWG silicone, 300 mm | Axisflying specs and drawing |
| In the box | 1 motor, 4 × M3×6 mm screws, 1 M5 nut (from the product-list image; the page text lists 4 × M3×8 screws, an M3×4 shaft-lock screw, an M5 flanged nylon-insert lock nut, an O-ring and 2 washers (S1)) | Axisflying test data |
Bench data
Redrawn from Axisflying’s test reports. Thrust is static pull on a bench, more than you get in flight. Power is volts × amps; efficiency is thrust divided by power.
900KV on 3S–6S, 25 V2 props
| Prop | Throttle | Voltage (V) | Current (A) | Thrust (g) | RPM | Power (W) | Efficiency (g/W) |
|---|---|---|---|---|---|---|---|
| GF 10*5 3-blademotor at 98.3 °C | 50% | 25 | 11.6 | 1,426 | 8757 | 290 | 4.92 |
| 60% | 25 | 18.2 | 1,933 | 10064 | 455 | 4.25 | |
| 70% | 25 | 28.1 | 2,585 | 11451 | 702.5 | 3.68 | |
| 80% | 25 | 39.1 | 3,159 | 12665 | 977.5 | 3.23 | |
| 90% | 25 | 54 | 3,768 | 13720 | 1350 | 2.79 | |
| 100% | 25 | 64.7 | 4,185 | 14612 | 1617 | 2.59 | |
| HQ MQ 9*5 3-blademotor at 75.6 °C | 50% | 25 | 10.7 | 1,287 | 9052 | 267.5 | 4.81 |
| 60% | 25 | 16.7 | 1,778 | 10921 | 417.5 | 4.26 | |
| 70% | 25 | 25.8 | 2,266 | 12442 | 645 | 3.51 | |
| 80% | 25 | 36.4 | 2,815 | 13189 | 910 | 3.09 | |
| 90% | 25 | 48.8 | 3,325 | 14488 | 1220 | 2.73 | |
| 100% | 25 | 58.1 | 3,712 | 15172 | 1452.5 | 2.56 |
Source: Axisflying test data
Inside the motor
A brushless outrunner: the coils stand still in the middle and the magnets spin around them. From the top down:
- Bell. Black, with twelve straight spokes on the top. (Axisflying product photo, Axisflying top-view photo)
- Shaft. 5 mm with an M5 thread, 11.2 mm of it threaded, standing 16.7 mm above the bell. (Axisflying specs and drawing)
- Stator. 31 × 15 mm, 12 slots, with 14 magnet poles in the bell. (Axisflying product page, Axisflying specs and drawing)
- Leads. 18 AWG silicone wire, 300 mm. (Axisflying specs and drawing)
How fast it spins
KV is the motor’s no-load speed per volt. With nothing on the shaft, the 900KV version reaches about these speeds; a prop loads the motor and brings it down, typically to around 70–75% of these figures at full throttle.
| Battery | Volts | No-load rpm (KV × V) | Electrical frequency | ESC steps per second |
|---|---|---|---|---|
| 4S nominal | 14.8 | 13,320 | 1,554 Hz | 9,324 |
| 4S full | 16.8 | 15,120 | 1,764 Hz | 10,584 |
| 6S nominal | 22.2 | 19,980 | 2,331 Hz | 13,986 |
| 6S full | 25.2 | 22,680 | 2,646 Hz | 15,876 |
A 14-pole rotor has 7 pole pairs, so every turn of the shaft is 7 electrical cycles, and a six-step ESC switches the phases 42 times per turn.
About the 3D model
A generic outrunner drawn from Axisflying’s published sizes: the 31 × 15 mm stator, 37.1 mm bell, 31.5 mm height, 5 mm shaft, 19 mm mounting circle and 12 teeth and 14 magnets. Anything Axisflying doesn’t publish is typical for a motor this size, and the bell’s spoked top, the base and the inside are a generic design, not this motor’s. The colours are read off the maker’s product photos. There are no logos or markings: it is our drawing, not the maker’s.
